Model: Sohigh LiBAT-200AH-51.2V
Brand: Sohigh Solar
Voltage(V): 51.2V
Product Origin: Guangzhou,China
Capacity: 150Ah
Material: Lithium ion
Features of the 51.2V 150AH lifepo4 battery
Sohigh Solar 51.2V150AH Battery is a state-of-the-art lithium battery that works at 51.2V with integrated BMS module for remote control
The Sohigh Solar 51.2V150AH lithium battery is part of the Sohigh Solar lithium battery series that is characterized by a 51.2V LiFePO battery pack.
They are high performance batteries that serve both for isolated installations, network installations and for self-consumption installations with batteries or accumulation.
The Sohigh Solar 51.2V150AH 7.68kWh lithium battery has an intelligent BMS module that allows administration, centralized remote support and battery monitoring (voltage, current, temperature of the cells and of each module, overload protections, etc.), and administration and remote maintenance of the battery, in this way the balance of each cell is achieved and the current is limited during the charging process to ensure the safety and efficiency of the battery.
Technical characteristics of the 7.68kWh Sohigh Solar 51.2V150AH Lithium Battery
It is a LiFePO4 battery (lithium iron phosphate), so its internal technology has all the advantages inherent in the latest generation lithium batteries.
The Sohigh 51.2V150AH 7.68kWh lithium battery is of high energy density and light weight compared to other batteries in the market with similar technical characteristics.
Its internal technology enjoys a long service life even when its usual use of deep cycles.
It is a battery with a fast charge capacity compared to other batteries of a similar range, so waiting times are minimized.
The 51.2V150AH 7.68kWh lithium battery has an integrated battery management system (BMS) that by controlling the temperature, voltage, etc. guarantees both the safety of the accumulator and the integrity of the other connected elements, optimizing Battery operation at all times.
The front of the battery incorporates an LED light that indicates the percentage of remaining energy autonomy.
The Sohigh Solar 51.2V150AH 7.68kWh battery has a low self-discharge rate and no memory effect.
This battery does not emit gases during operation or at rest, which allows you to install the battery inside the home if you wish.
Since it is a lithium battery, it does not require maintenance or periodic control of its internal levels, so after installation it does not require manipulation.
Although the above points define the character and operation of the battery, without a doubt the characteristic that makes the Sohigh Solar 51.2V150AH 7.68kWh lithium battery one of the most efficient in the market is its discharge capacity as this battery is capable of discharging 100%, since its useful capacity and real capacity is the same, something that does not occur in other lithium batteries.
| Electrical Characteristics | Nominal Voltage | 48V | |||
| Nominal Capacity | 200AH | ||||
| Energy | 9600Wh | ||||
| Internal Resistance | ≤500mΩ | ||||
| Cycle Life | >3500 cycles @1C 100%DOD | ||||
| Months Self Discharge | <3% | ||||
| Efficiency of Charge | 100% @0.2C | ||||
| Efficiency of Discharge | 96~99% @1C | ||||
Standard Charge | Charge Voltage | 54.8±0.2V | |||
| Charge Mode | 0.2C to 14.6V, then 14.6,charge current 0.02C(CC/CV) | ||||
| Charger Current | 30A | ||||
| Max. Charge Current | 30A | ||||
| Charge Cut-Off Voltage | 55.5V±0.2V | ||||
Standard Discharge | Continuous Current | 100A | |||
| Max. Pulse Current | 150A(<3s) | ||||
| Discharge Cut-off Voltage | 37.5V | ||||
Mechanical | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity | |||
| Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | ||||
| Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity | ||||
