Model: Sohigh BAT-800AH-2V
Brand: Sohigh Solar
Voltage(V): 2V
Product Origin: Guangzhou,China
Capacity: 800AH
Description of 2V 800AH Battery
The deep cycle gel battery consists of a gel rather than a liquid, so no maintenance is required to keep the battery working properly. The gel cell deep cycle battery is manufactured using advanced valve-regulated technology with a narrow operating pressure range. It is equipped with explosion-proof and acid filters to avoid acid leakage and frequent maintenance.
The deep cycle battery has an extended service lifespan with a design life of up to 18 years in standby applications. The deep cycle gel battery is made of high purity materials that reduce monthly self-discharge to less than 2.5% at 77°F (25°C), 5 times lower than liquid-rich batteries. No need to recharge dormant batteries frequently.
Sohigh Solar is a professional deep cycle battery factory and deep cycle battery supplier in China, offering the 12 volt gel cell deep cycle battery, 200ah 12v gel deep cycle battery, the best AGM deep cycle marine battery, VRLA deep cycle battery, and so on at affordable prices!
| Rated Voltage | 2V | |||
| Nominal Capacity | 800AH | |||
| Capacity(25℃) | 10HR(1.8V) 800Ah 3HR(1.80V) 600Ah 1HR(1.75V) 440Ah | |||
| Terminal type | T20 | |||
| Internal resistance (Fully charged,25℃) |
Approx.0.40mΩ
| |||
Capacity affected by temperature (10HR) |
40℃ 102% 25℃ 100% 0℃ 85% -15℃ 65% | |||
| Self-discharge (25℃) | 3 months Remaining Capacity: 91% 6 months Remaining Capacity: 82% 12 months Remaining Capacity: 65% | |||
Operating temperature range |
Discharge -15℃ ~ 50℃ (5℉ ~ 122℉) Charge -10℃ ~ 50℃ (14℉ ~ 122℉) Storage -20℃ ~ 50℃ (-4℉ ~ 122℉) | |||
| Nominal Operating Temp. Range | 25℃ ± 3℃ (77℉ ± 5℉) | |||
| Float charging voltage(25℃) |
2.25 to 2.30V Temperature compensation:-3mV/℃ | |||
| Cyclic charging voltage( 25℃) |
2.40 to 2.50V Temperature compensation:-5mV/℃
| |||
| Maximum discharge current | 4400A(5 sec.) | |||
| Designed floating life( 20℃ ) | 18 years | |||
| Maximum charging current | 160A | |||
