Model: MC4-T3 (2-1)
Brand: Sohigh Solar
Product Origin: Guangzhou,China
Description of the Solar Connector
The Multi-branch connectors with 2 inputs create a parallel connection between two solar panels. Increase the current rating of the PV string with safe and water-proof connectors. Ideal for off grid , grid tie and hybrid installations.
Multi-branch MC4 Connector For Paralleling Solar Panels
When two panels operate in parallel the positive cables are connected together and negative cables are also shorted together. Paralleling increases the current at max power point (Imp) while the voltage remains the same.
For example, the solar panels with 8Amps Imp and 18V Vmp, if two identical panels are connected together the amps will be 16Amps and the voltage will remain at 18V.
If only two panels are required the Multi branch MC4 connector is the easiest and safest method. It is obvious that the two positive male and two negative females can not be connected together, that’s why the multi-branch connectors will fulfill this connection.
| Product Name | Solar Connector T Branch 2 To 1 | |||
| Product Type | Connectors | |||
| Rated Voltage | 1500 V | |||
| Rated Current | 20A (4mm²) 30A (6mm²) | |||
| Contact Material | Tin Plated Copper | |||
| Protection Degree | IP67 | |||
| Contact Resistance | ≤0.5mΩ | |||
| Pollution Degree | -40℃~+85℃ | |||
| Ambient Temperature | 2.5mm², 4.0mm², 6.0mm² | |||
