Features of the 25.6V 100AH lifepo4 battery
Longer Life Span
Up to 80% capacity for 3000 cycles in recommended conditions. The typical SLA has 300-400 cycles. ECO-WORTHY Lithium batteries last so long that the price per use is a fraction of traditional batteries.
Lightweight Champion
Our lithium battery is only 1/3 of the weight of a lead-acid battery, easy to move and install. It is an ideal choice for outdoor camping power supply and simple indoor installation.
High Efficiency
It provides up to 95% of their rated capacity while a lead-acid battery is usually limited to 50%. You get all the juice down to the last drop. It can support fast charging or solar panel charging.
Extremely Safe
LiFePO4 batteries are safest battery type available today. ECO-WORTHY lithium battery has a built-in Battery Management System(BMS), we can guarantee the safety and reliability of our batteries.
Wide Application
Suitable for RVs, Solar systems, off-grid, Boats, Fish finders, Power wheels, Scooters, Industry, Hiking, Camping, Backup power supply, etc.
Electrical Characteristics | Nominal Voltage | 25.6V | |||
Nominal Capacity | 100AH | ||||
Energy | 2560Wh | ||||
Internal Resistance | ≤200mΩ | ||||
Cycle Life | >3500 cycles @1C 100%DOD | ||||
Months Self Discharge | <3% | ||||
Efficiency of Charge | 100% @0.2C | ||||
Efficiency of Discharge | 96~99% @1C | ||||
Standard Charge | Charge Voltage | 29.2±0.2V | |||
Charge Mode | 0.2C to 14.6V, then 14.6,charge current 0.02C(CC/CV) | ||||
Charger Current | 20A | ||||
Max. Charge Current | 100A | ||||
Charge Cut-Off Voltage | 14.8V±0.2V | ||||
Standard Discharge | Continuous Current | 150A | |||
Max. Pulse Current | 300A(<3s) | ||||
Discharge Cut-off Voltage | 20V | ||||
Mechanical | Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity | |||
Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | ||||
Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity | ||||
