Lifepo4 Battery 12V 200AH

QR code
Model Sohigh LiBAT-200AH-12V
Brand Sohigh Solar
Voltage(V) 12V
Product Origin Guangzhou,China
Capacity 200A
Material Lithium ion
Parameters
Model
Sohigh LiBAT-200AH-12V
Brand
Sohigh Solar
Voltage(V)
12V
Product Origin
Guangzhou,China
Capacity
200A
Material
Lithium ion
I know
Product DetailParameterDatasheet


About the 12.8V 200AH lifepo4 battery

The battery's proprietary lithium-iron phosphate chemistry takes the hassle out of maintaining and utilizing the power you need. Batteries are meant to be used when you need them and if you need them all the time then lead-acid becomes too unreliable and exhausting to keep track of. The lithium chemistry of the battery cuts the weight of the traditional lead-acid battery to less than half while providing a massive boost to performance and capacity so you won't miss a single second of runtime. Designed for more than just storing power easily, they're here for you to provide long-lasting peace of mind with their immense durability making it easy to use them in your home, at your job, or for your outdoor needs where trust, safety, and the environment matter most.





Features of the 12.8V 200AH lifepo4 battery

Longer Service Life: Our LiFePO4 battery provides 2500 - 7000 cycles & a 10 years lifetime compared to 200 - 500 cycles & a 3 years lifetime in typical Lead Acid chemistry.


Efficient Power: Our LiFePO4 battery’s flat discharge curve holds above 12V for up to 95% of its capacity usage providing astronomical boosts in run-time compared to only 50% in Lead Acid.


Impeccably Lightweight: Our LiFePO4 battery is only a 1/3 of the weight of Lead Acid which makes it the disputable choice for RVs, Marine and Off-Grid Applications when towing or mobility is in the consideration.


Complete Protection: The lithium battery’s unique built-in Battery Management System (BMS) protects it from overcharge, deep discharge, overloading, overheating and short circuit, and excessive low self-discharge rate ensuring up to 1 year maintenance-free storage. Built-in low-temp cut off prevents charging under 23 °F (-5 °C).













Electrical Characteristics

Nominal Voltage

12.8V

Nominal Capacity

200AH

Energy

2560Wh

Internal Resistance

≤200mΩ

Cycle Life

>3500 cycles @1C 100%DOD

Months Self Discharge

<3%

Efficiency of Charge

100% @0.2C

Efficiency of Discharge

96~99% @1C





Standard Charge

Charge Voltage

14.6±0.2V

Charge Mode

0.2C to 14.6V, then 14.6,charge current 0.02C(CC/CV)

Charger Current

80A

Max. Charge Current

150A

Charge Cut-Off Voltage

14.8V±0.2V


Standard Discharge

Continuous Current

150A

Max. Pulse Current

450A(<3s)

Discharge Cut-off Voltage

10V


Mechanical

Charge Temperature

0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity

Discharge Temperature

-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity

Storage Temperature

0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity



LiFePO4 Battery Datasheet-Sohigh Solar.pdf
